Product Introduction:

Wedge pins are used with flat tie to tighten adjoining concrete forms, securing the flat tie and concrete form in place. The full set of the Symons Formwork Accessories including the Wedge Bolt, Long Bolt, Short Bolt, X-Flat Tie, One Piece Waler Clamp, Z Tie Holders & Waler Tie, J-Strongback Hooks and Strongback Ties, Scaffold Brackets and Turnbuckles.

Product Details




Steel Ply Forming Accessories X Flat Tie

The avaliable size from 4" to 48" wall thickness as your request.


Product

 Name

Wall

Thickness

Weight

(g)

Weight

(LBS)

Ultimate

Load

Packaging

Steel Plywood Forming Accessories X Flat Tie


X-FLAT TIE
4"103.980.22926000LBS

100pcs/carton;

10,000pcs/pallet


5"111.90.2467
6"119.810.2641
8"141.210.3113
9“151.910.3349
10”162.610.3585
12“184.010.4057
14”205.410.4528

50pcs/bundle;

2,500pcs/pallet

15“216.110.4764
16”226.810.5000
18“248.210.5472

50pcs/bundle;

2,500pcs/pallet

20”269.610.5944
22“291.010.6416
24”312.420.6888
............
48“569.221.2549

25pcs/bundle;

2,500pcs/pallet

Accessories

PictureProduct NameMaterialWeightSurface Treatment Packaging
Steel Plywood Forming Accessories X Flat Tie


Standard

Wedge Bolt


45#

Steel


    52g



 heat

treatment


500pcs/pail then put on pallet

Steel Plywood Forming Accessories X Flat Tie


Long

Wedge Bolt


71g


250pcs/pail then put on pallet

Product Detail:
Steel Plywood Forming Accessories X Flat Tie

Steel Plywood Forming Accessories X Flat Tie

Application:


Steel Plywood Forming Accessories X Flat Tie

Packaging :

Steel Plywood Forming Accessories X Flat Tie

Related Produts:

Wedge bolts connect panels and ties together, eliminating the need for special tools or equipment in the set up process. Two identical wedge bolts work as a single lock-bolt set, connecting and clamping together. However, additional bolts may be needed for walker attachments, scaffold brackets, etc.

X Flat Ties are used with Wedge Bolts to secure and space modular forms.  X Flat ties are available in 6″ up to 84″ in 1/2″ increments. Standard breakback is 1/4″.

One Piece Waler Clamps attach through the wedge bolt slot of modular type forms to provide wedge action aligning with single or double lumber.

Z Tie Holders are used in conjunction with Waler Ties to secure double 2x lumber wales to modular type forms.  The Waler Tie is available in two sizes to accommodate 2 x 4 and 2 x 6 lumber.

Turnbuckle Form Aligner Lumber forms (also refers to as kickers) which brace and support the fully assembled wall from the fluid pressure of the concrete.

Attach a file
